    Kiosk / ATM CCD Barcode Scanner Engine High Sensitive Linear Image Sensor

    Ask Lasest Price
    Brand Name : symcode
    Model Number : MJ-2060S
    Certification : CE FCC ROHS IP54
    Payment Terms : T/T, Western Union, L/C, D/A, D/P, MoneyGram
    Supply Ability : 50,000pcs per month
    Delivery Time : Sample order:1-3 days / Bulk order:7-15days
    • Product Details
    • Company Profile

    Kiosk / ATM CCD Barcode Scanner Engine High Sensitive Linear Image Sensor

    Kiosk/ ATM CCD Barcode Scanner Module

    from Symcode Factory MJ-2060S


    Features

    MJ-2060S is a perfect choice for your OEM design. It has been designed to provide the highest scanning performance in the smallest package possible. For added versatility, allowing for fast, cost-effective interchangeability when upgrading or modifying your OEM device for specialized applications.


    MJ-2060S is a compact long-range CCD bar code scanning module with high sensitive liner image sensor. It has a good penetrability that can read 1d barcodes covered by plastic or glass. As remote-operation ability 10,000 LUX ambient light resistance, 500 scan-rate per second and aiding in various major bar codes, hand-on software-programming function, this MJ-2060S is your best choice of CCD type bar code scanning module to be suitable for application where needs a high performance, small foot-print and the reliable operation.


    light sourceVisible red light, wavelength 632nm
    Optical systemLinear CCD Sensor
    processorARM32-bit
    Resolution1500
    definition≥4mil/0.1mm(PCS90%,CODE 39)
    Read depth of field50mm~600mm
    Decoding speedUp to 300 times / sec
    Read modeManual reading, automatic reading, induction reading
    Read angleTest Conditions:CODE39,10mil/0.25mm,PCS90%
    Tilt Pitch:±60°
    Rotate: ±30°
    Skewed : ±60°
    Print contrast≥25%
    Ambient light intensity0-100000LUX
    Reading code systemUPC-A,UPC-E,EAN-8,EAN-13,ISSN,ISBN,Code 128, GS1-128, Code 39,Code 93, Interleaved 2 of 5, ITF-6, ITF-14,Matrix 2 of 5,Industrial 2 of 5,Standard 2 of 5(IATA),Codabar(NW-7),Plessey,MSI Plessey,RSS,etc.
    Size21.6mm*13*16.2
