    2 Track Magnetic Card Reader And Writer Bidirectional Read Capability

    Ask Lasest Price
    Brand Name : symcode
    Model Number : MSR-002
    Certification : CE / RoHS / FCC
    Payment Terms : T/T, Western Union, D/P, D/A, L/C
    Supply Ability : 50,000pcs per month
    Delivery Time : Sample order:1-3 days / Bulk order:7-15days
    • Product Details
    • Company Profile

    2 Track Magnetic Card Reader And Writer Bidirectional Read Capability

    2 track magnetic card reader and writer, support for magnetic card​


    1.Manual swipe type reader

    2.Bi-direction read capability

    3.Cover: Plastic
    4. USB port
    5.Operation responded by two LEDs and buzzer
    6.Power supplied by PC keyboard
    7.Small size.
    8.DLL/OCX developing kit for Windows98/ME/NT/2000/XP
    9.Sleeping mode (power saving)


    Not using this for a POS system?! No problem, these readers will read any type of magnetic card with up to 3 tracks of data. Credit cards, debit cards, ID cards, Security cards, driver's licenses, badges, insurance cards...... ANY TYPE OF MAGNETIC CARD!


    Need to program the reader to skip certain tracks? Remove the beginning or ending track sentinels? No problem, they can be programmed to your needs, just e-mail us for the link to download the programming software at anytime!


    Application

    1.Government: Driver Licence, Health Card, Government ID
    2.Card Verification: Age verification
    3.Any movable data collection Trade shows, Racing events
    4.Employee’s Time / Attendance data collection


    Power requirements+24VDC +/- 5%
    ConsumptionTypical 350mA Max. 600mA plus for each writing track
    Power supplyExternal switching power 24V/2.5A
    InterfaceSerial interface or USB
    Ripple50mVp-p or less
    Dielectric strength500 VDC for 1 minute
    Performance
    Read cardTrack1Track2Track3
    Bit per density210 bpi75/210bpi210 bpi
    Coercive forceRead/write 300-4000 oe Mag.card
    Card thickness0.76-1.2mm
    Read speedSTD cardJitter +/-15%Amp. 60%
    5-55ips5-50ips5-50ips
    Write speed5-30ips
    Write jitterInterval < +/- 10%, Sub-interval < +/- 12%
    Error rateRead < 0.5%
    Write < 0.8%
    Head lifeMin. 1000K swipes for both read/write head
    Physics
    Body materialABS 94V-0
