Wholesale High Quality Industrial Thermal Transfer
Direct Thermal Label Printer
How do we ensure the high quality?
First, we own the advanced production facilities for manufacturing
printers.
Second, our company employee the skill-full workers, almost service
in our company for over 8 years.
Third, we have the professional team in sourcing and quality
inspection team. Every printer will request for abundant of times
inspection from raw material to a finished product, such as raw
material sourcing assessment, incoming material inspection, PCB
board test, auto cutter test, printer-head test... finished printer
test and so on.
Four, our experienced packing team will pack every printer in
strong carton in best way for air/seaworthy transportation.
We would like to have our own brand, is that ok?
Rongtatech: Yes, we can accept OEM/ODM with your brand or your
design. But we will require a MOQ for different models.
Besides the English language, do your printers support other
languages? And what operation system they backup?
Rongtatech: Yes, our printer not only supports English language,
but also Russian, Spanish, Portuguese etc 48 different languages
available, and it backups IOS, Android, Windows, Linux, Oppos
operation systems.
| Print methods | Direct thermal & thermal transfer |
| Resolution | 203 DPI (8 dots/mm) & 300 DPI (11.8 dots/mm) |
| Maximum print speed | 6 IPS(152.4 mm/s) & 4 IPS(101.6 mm/s) |
| Maximum print width | 4.09″(104 mm) & 4.15″ (105.6 mm) |
| Maximum print length | 157.5″(4000mm)& 78.7″(2000mm) |
| Memory | 2 MB FLASH ROM, 2 MB SDRAM |
| Media | Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain
paper or thermal paper
Width:4.5″(114 mm) max.,0.8″(20 mm)min.
Supply roll: OD 5″(127 mm) max., ID 1″(25.4 mm) min.
Thickness: 0.08～0.20mm(0.003″～0.0078″), including liner |
| Ribbon | Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″(70 mm) max. with ID 1″(25.4 mm) core or ID
0.5″(12.7mm) core
Max width: 110 mm;
Max length: 300 M |
| Media sensor | Adjustable reflective & Transmissive |
| Bar Code Types | 1D Barcode : Code 39,Code 93,Code
128,Codabar,EAN-8/13/128,Interleave
2 of 5,UCC-128,UPC A/E 2 and 5 add-on, etc.
2D Barcode : Data Matrix, MaxiCode, PDF417,QR, etc. |
| Interfaces | RS-232 serial, USB |
| Power rating* | 24 VDC, 2.5 A |
| Weight | 2.62 KGS |
| Dimensions | W208 x D310 x H195 mm |
Operation
environment | Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing |
| Storage environment | Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing |
| Optional items | Peeler kit, Internal 100/10 M Ethernet Interface card |
